Self Tapping Screw Guide

The Science of the Turn:
A Five-Point Guide to
Self-Tapping Screws



1. What Are Self-Tapping Screws?

A self-tapping screw is designed to form its own threads as you drive it into a material such as wood, plastic or metal. In the past, you had to drill a guide hole before driving in whatever kind of screw would be used. Self-tapping screws create their own hole as pressure is exerted on them. They also provide a close, tight grip and a degree of certainty that the hole and screw fit exactly.

Self-tapping screws sound simple, but the science behind them is complex, and the choices within the realm of self-tapping screws are astounding. Within the self-tapping screw family are members that cut threads and others that form threads.

A self-tapping thread-forming screw would typically be used in plastic, and it deforms the material as it enters and drives inward.

A self-tapping thread-cutting screw would typically be used in wood or metal, and it cuts material out of its way as it enters and drives inward.
Self-tapping screws are normally made either from carbon steel or stainless steel, but they have other qualities that change their appearance and chemical composition. Stainless is the most commonly found screw material, often chosen for its corrosion resistance and is made with varying strengths that depend on the amount of nickel, chromium and other alloys they contain.

A screw well-fitted to the job not only means efficiency and quality but also durability and long life. Some people may ask: “How do you use self-tapping screws?” The answer is simple. They’re used like any other screw, where the user drives them in with a drill, screwdriver or machine.

2. What Are Some Characteristics and Applications of Self-Tapping Screws?


The science behind the turn of self-tapping screws is extensive and involves multiple factors:

Coating (If Any): Screws may be coated with polish, with nickel, copper, zinc or tin plating, with phosphate, oxide lacquer and possibly other materials depending on the purpose they’re serving and the finish and performance that’s expected.

•  Color: Surface treatments on self-tapping screws cater to an array of uses since they come in a rainbow of colors such as yellow, blue, green, gray, black, silver, copper and extra-bright hues.

•  Composition: Some engineering calculations are necessary to determine the correct alloy mix that achieves the desired hardness of many kinds of self-tapping screws.

•  Diameter: When it comes down to holding something in place, the girth of a screw plays a key role. The self-tapping screw diameter should be matched to the job, whether light or heavy.

•  Hardness/Strength: Similar to the composition of self-tapping screws is the heat treatment that tempers the screws to the desired hardness. The amount, duration and temperature of the heat all make a difference in the end product.

•  Head Style: The head refers to the shape of the screw’s top, which may be round, oval, square, flat, socket, fillister or hexagonal.

•  Length: People are probably most familiar with this characteristic of a self-tapping or another kind of screw. The length of the screw makes all the difference in whether it can reach and dig into its target without going too deep.

•  Recess: The recess is the part of the screw that receives the screwdriver or drill. It can have a variety of shapes such as square, slot, Phillips and hex.

•  Thread: Self-tapping screws do their work by way of the size, density and pattern of the thread on them. All of the thread’s elements, from how closely together the thread sits to how many rows of it there are and where they begin and end, play a huge role in the science of the turn.

•  Tip: The point of a screw holds a lot of potential to penetrate the material, tap a proper hole and hold fast. Screw tips may range from having a fine, sharp shape to a blunt edge.

Self-tapping screws may have a range of these characteristics, most likely to match one of the many applications for which self-tapping screws are used. They use these characteristics to complete the essential work of holding other larger pieces in place. The following are just a few of the possible applications for self-tapping screws.

•  Gutters: Self-tapping screws are usually the foundation of any gutter-attachment system. They make for less work, a secure hold and a finish that will withstand a beating from the water and rooftop debris. The right screws will hold the gutters in place, withstand weather, resist corrosion, look neat and not drive too deeply, among other things.

•  Medical: We don’t think of our bodies as a place where screws would go, but that’s exactly what happens in any number of replacements and other kinds of repair surgery. Medical articles routinely mention self-tapping screws and expound on their functionality for fastening parts inside the body. For example, dental implants that attach by screwing into the jaw bone are big, self-tapping screws with a tooth or teeth on top.

•  Roofs: Self-tapping screws make the shingle and framing work go smoothly and can be ordered for whatever type of roofing materials you might use. Asphalt, wood and metal each have properties to which the screw can be matched for maximum grab, hold and endurance.

•  Drywall: Hanging drywall is another place where self-tapping screws excel because of their threads. The pattern is designed to dig itself in tightly and hold fast, and the length penetrates whatever thickness of drywall is chosen. The right screws can make the difference between walls that hang straight, look good and last, and ones that don’t.

•  Sheet Metal: The driving action and special drill-like tip of self-tapping screws are needed to work with various metals of different thicknesses. The screws might be used for anything from a barn roof and automobile to building construction and artwork.

•  Plastic: The technology associated with self-tapping screws for plastic has evolved to the point that the pieces are now specialized and sometimes made of plastic themselves. Self-tapping screw technology has evolved to include more lightweight materials such as plastic and aluminum and shorter thread engagements.

The American Society of Civil Engineers did some testing with cross-laminated timber, which is growing in popularity. It found self-tapping screws to be sufficient for creating shear joints and bearing vertical loads associated with three-ply and five-ply laminate.

3. How Would You Use Self-Tapping Wood Screws?

All hardware stores that are in fact worth the name possess a broad array of things like wood screws and nails and bolts and tools for using these items. To make matters even much more difficult, every kind of securer and tool may possess a somewhat unique technique to using it correctly. Let us consider a look at how you should probably make use of wood screws and what you do not do using wood screws.

The first factor to notice about wood screws is you receive individual tapping anchoring screws as well as regular wood screws. The individual exploit screw commonly is quite a few simpler to set up as well as will take quite a few much less function. All you need to do is make use of whether a Philips or flat head screw driver and set the point of the fastener as a spot you want it to be and start screwing. As you turn the actual screw driver the actual screw could cut in to the wood and make a hole for itself. Absolutely no drills required After that there is the normal self-tapping wood fastener. You will require a drill for this one. You will have to mark out all of the locations that you’re going to need to place fasteners as well as drill a hole in the wood that is the correct size for the screws you are heading to be using. After that you need to go along and, although using the suitable type of screwdriver, fastener all the fasteners in to place.

The hazard with using each kinds of fasteners is you don’t get all of them in straight. A individual tapping fastener might perhaps get picked skew by the grain of your timber or by you placing unequal pressure as a screw driver as you flip it into the wood. If you work with a drill then you definitely run a slightly decreased risk of going skew as you are not being expected to place many pressure on your drill to bite into the precise wood and the drill isn’t most likely to get pushed around because of the grain of the wood. As an alternative you risk using a drill bit that’s a tiny bit too big for the anchoring screws you will probably be making use of in the do-it-yourself venture that means which the fastener is not going to hold.

In addition, you want assure that you will get the greatest sort of fasteners using regards to the materials they’re produced from. Some metals have a tendency to be far more corrosion proof in contrast to other plus most could leave an awful spot if you use them in wood simply because they react to the actual sap even now still left in the wood. So initially do most study and ascertain precisely what you’ll need and what type of screws you are going to be utilizing.

Picking the finest type of fastener for any job might not be as basic as it appears once the specialists get it done. There are actually lots of issues to look at earlier than you commit to a specific wood screw or nail for you specific do-it-yourself venture. If you’re not sure, ask for help and get this correct.

4. What Industries Use Self-Tapping Screws?

The following are just a few examples of the many industries that regularly use self-tapping screws.

•  Agriculture: No matter the size of the agricultural operation, there are tractors, barns and pole sheds, machines and some custom-made contraptions that require a mix of self-tapping screws for nearly every kind of material that needs to be fastened.



•  Automotive: From hood to trunk, self-tapping screws can be found throughout most vehicles including cars, trucks, campers, buses and more. They’re at work throughout the entire transportation industry.



•  Aviation: An airplane and its panels are often held together with high-strength self-tapping screws, and it’s an environment where the screws also facilitate the transition from metal to plastic or wood.



•  Construction: From framing to finishing touches on homes or commercial buildings, the construction industry uses millions of self-drilling, self-tapping and self-piercing screws.



•  Dental/Orthodontic: Self-tapping and self-drilling screws are so prevalent in the oral-health industry that there was a study conducted to figure out which type worked better in the human mouth. It concluded they were both effective, but a fine tip of a tapper was better near the tooth root.



•  Decks: Self-drilling and self-tapping fasteners help create new or renewed outdoor living spaces, and they do the job with any choice of material including wood, composite and steel.



•  Drywall: Anyone hanging drywall or another kind of gypsum product knows how essential self-tapping screws are to getting the heavy-duty job done.



•  Heating/Ventilation/Air Conditioning: Plumbing-HVAC professionals have a large supply of self-tapping screws for the ductwork, vents, condensing units and other pieces they encounter on the job.



•  Refrigeration: Refrigerators, freezers and other such equipment consist of sheet metal fastened with self-tapping screws to various forms of insulation.



•  Roof/Gutters/Siding: Flashing, vents, shingles, brackets and other elements found throughout roofing and siding jobs are optimally fastened with self -tapping/drilling/piercing screws.



•  Utilities: Power boxes and many of the other accouterment of a water, electric, gas or another kind of utility include self-tapping and self-driving screws to fasten on metal panels and other small, metal or plastic elements.



•  Woodworking: Any good woodworker has explored the many possibilities of screws available to hold their project together, from homes and furniture to art and hobbies. Those who work with wood also know how the various types of wood and their hardness and other characteristics may call for a special kind of screw or tip.



•  Warehousing: Warehouses are typically chock-full of self-tapping screws, on metal shelves, sheets and other places, depending on the configuration and nature of a plant.



There are screws for going from metal to wood, gypsum to wood and all the other combinations of materials you might find together in building projects and other industry or specialty uses. Many times, you can find and get the perfect fastener just by consulting experts to whom you can explain your project so they can help match the fastener to the job.

4. Are There Differences Between Different Kinds of Fasteners?

There are millions of kinds of fasteners, and knowing the best type to use is a point of quality and a boost to businesses. There are similarities and differences between self-tapping, self-piercing and self-drilling screws. The thread, head and tip distinguish one from the other, as well as the intended use of the fastener.

Self-tapping screws are known for their ability to drill their own hole as they go along, as opposed to drilling a pilot hole like with flat-ended screws. They can have a sharp or blunt tip. A sharp tip is usually for drilling into softer materials, such as wood or plastic, without having to drill a pilot hole. The blunt tip helps your success rate when drilling into something harder, like metal. Self-tapping zip screws are especially useful for projects involving metal buildings or gutters, for example.

Self-tappers are often used in sheet-metal applications where one-sided access is an issue. This might be applicable in automotive, aviation and other industries. The technology has overcome what used to be a challenge for many industries — fastening together thin metal safely with a screw. Self-tapping screws are used for a wide range of applications involving steel and aluminum, as well as alloys and mixed applications. They handle metal gauges from about 24 through 30.

Self-drilling screws have a fluted tip, almost like a drill bit, to dig into the material before its threads drive through it. You will also see and hear these called Tek® screws, pro points and drill-bit screws. They also come with a variety of options for the head, tip and other characteristics. The self-drilling screws are what you need to penetrate thicker metal such as 22 gauge.

Self-drilling screws are used for many metal applications but weren’t intended to go from metal to wood. For that, there is a specialty self-drilling screw called a reduced point Tek. Most of the time, it is this type of screw that makes the deck-to-building connection in a deck-construction project. These types of screws have tips numbered one through five, which refers to the thickness of the metal it can penetrate without a pilot hole.
Self-piercing screws feature an ability to pierce light-gauge metal and as they’re driven, tap their mating threads. They have a sharp angle of about 30 degrees and are considered a high-strength fastener. You will regularly see and hear self-piercing screws referred to as zip, needle- or pencil-point screws, as well as self-tapping screws.

In fact, it isn’t unusual for all the terms to be used and mixed interchangeably for any screw-type fastener that doesn’t have a flat bottom, despite the differences among them. The three types described here work in similar ways, and some specialty screws have twin or dual characteristics and functions.

The American Society for Testing and Materials (ASTM) conducts analyses of self-tapping screws to be sure the science for the turn is correct. The tests ensure the screws are being manufactured to established standards and will perform as expected. These standards test the screws’ following qualities:

•  Assembly tension
•  Chemistry
•  Corrosion resistance, which entails a salt-spray test
•  Dimensions
•  Drill capacity, drive and hole size
•  Ductility
•  Hardness
•  Hydrogen embrittlement
•  Plating/coating thickness
•  Torsional strength

5. FAQs About Self-Tapping Screws

Although self-tapping screws have become common because of their convenience, people typically have several questions about how they work. All Points Fasteners is here to help!

Can You Use a Self-Tapping Screw in the Same Hole Twice?

No. Since the material’s substrate can become damaged when removing the screw, so it is necessary to use a new screw. The replacement self-tapping screw should have a larger diameter to rethread the hole and ensure a secure fixing.

How Do You Identify a Self-Tapping Screw?

Any screw that doesn’t need a nut and can tap it’s own threads into the material it’s penetrating, is a self-tapping screw.

6. What Types of Self-Tapping Screws Are for Sale at All Points Fasteners?

You can easily browse our expansive inventory of different types of screws and other fasteners to find what you want, and you can always contact us for help. All Points specializes in ceramic, stainless, copper, zinc and other types of screws that are self-tapping, self-drilling, self-piercing and any combinations of these. We also have a wide variety of sizes available.

To pluck a few examples, we carry screws for many specialized and everyday uses:

•  Drywall Tek self-drilling screws in six sizes, a black-oxide finish and quantities that range from 3,500 to 10,000 cases.

•  Hex washer head drill points self-drilling screws in a few dozen sizes with zinc-tipped steel composition and the option for painted heads.

•  Phillips flat-, pancake– and wafer-head self-drilling screws in zinc-plated steel.

•  Ceramic-coated self-piercing screws for gutters, siding, carports, barns and roofs.

•  Phillips and slotted sheet-metal self-tapping screws in several dozen sizes and made of steel with many options for coating.

•  Deck screws in self-tapping, piercing and drilling including flatheads, ceramic coating, bugle heads, square drivers, options for cedar and fasteners formulated to resist salt spray.

•  Woodworking screwsinclude versions for particle board, different wood hardness, front-facing wood and hinges, with black-phosphate and yellow-zinc finishes.

Consider All Points an expert partner you can consult anytime about the science of the turn. We’re here to listen, talk and provide any needed guidance. As seasoned veterans in our field and professionals who take pride in our work, we’re known for being able to find hard-to-find items. If you are looking for additional screw fact information check out more of our webiste.

Besides expertise in self-tapping, self-piercing and self-drilling screws, All Points also offers rivets, anchors, nuts, bolts, nails, washers, drill bits, cable ties, reciprocal saw blades and other products to help you fasten whatever it is your business requires. We’re happy to provide free samples and quotes, and we’re able to accommodate large-quantity orders quickly.

All Points is a nationwide distributor with years of experience that will benefit you and your business as you navigate the options and select the fastener that best fits your needs.
