Hex Washer Head Sheet Metal Screws

Sheet Metal

Hex Washer Head Sheet Metal Screws

Few sheet metal screws combine the performance and flexibility of the hex washer head screw. Designed for installation and removal with a Torx tool or flat screwdriver, you don’t have to worry about having the right tool handy. Add in their self-tapping A and A/B points and you can make quick work of all of your sheet metal installation projects with our hex washer sheet metal screws.

Like all of our screws here at All Points Fasteners, our hex head screws offer many great features that make them suitable for a wide range of sheet metal applications:

  • Quality steel for long-term reliability
  • Zinc coating for extended corrosion resistance
  • U.S. manufacturing to guarantee quality and consistency
  • Torx and slotted heads for increased versatility
  • Large flat bearing surface for additional load capacity

This combination of features makes our hex washer head sheet metal screws hard to beat. And because we sell them in bulk quantities ranging from 800 all the way up to 25,000 pieces per case, you’re getting domestic quality at an imported price. That kind of value saves you money — especially when you’re installing thousands of screws per month for all of your sheet metal projects.

Additional All Points Fasteners Advantages

On top of our great selection of sheet metal hex washer screws, we’re proud to offer many other great advantages and services:

  • If you don’t find the screws and fasteners you’re looking for in our catalog, we’ll find them for you.
  • We offer free samples you can try before you place your order, to give you more confidence.
  • Our team will prepare a fast and free quote with our best price on any type and quantity of screw.
  • You can contact us by phone, online message system or online contact form.

We’re proud of our reputation as a leading online source of high-quality, fasteners and screws. With over 50 different models of hex washer head sheet metal screws, you’re sure to find the one you’re looking for here.

Wide Range of Sizes

We’ve listed all of our diameter and length combinations on this page so you can quickly find the hex head screws you need for your sheet metal work. Choose from the following diameters and lengths:

  • #6, #8, #10, #12 and #14 diameters
  • 1/4” up to 4” lengths on various 1/4” and 1/3” increments

Take a few minutes to browse our catalog and identify the head sheet metal screws that will work best for you. Then let us know which quantities you’d like and we’ll prepare your free quote. Don’t forget to tell us if you’d like some free samples and we’ll ship those off to you quickly so you can give them a try.

stainless steel hex washer head

SLOTTED INDENTED HEX WASHER HEAD

  • TYPE A AND A/B POINT
  • ZINC PLATED STEEL
PART # SIZE THREAD TYPE LBS/M CASE QUANTITY
9163060 #6 x 1/4″ AB 2.1 25,000
9163062 #6 x 3/8″ AB 2.2 20,000
9163064 #6 x 1/2″ AB 2.3 20,000
9163066 #6 x 5/8″ AB 2.8 18,000
9163068 #6 x 3/4″ AB 3.1 16,000
9163070 #6 x 1″ A 3.8 14,000
9163072 #6 x 1-1/4″ A 4.6 10,000
9163074 #6 x 1-1/2″ A 5.3 8,000
9163076 #6 x 2″ A 6.6 5,000
9163078 #8 x 1/4″ AB 2.3 25,000
9163080 #8 x 3/8″ AB 2.7 16,000
9163082 #8 x 1/2″ AB 3.4 20,000
9163084 #8 x 5/8″ AB 3.6 16,000
9163086 #8 x 3/4″ AB 4.2 14
9163088 #8 x 1″ A 5.1 10,000
9163090 #8 x 1-1/4″ A 6.0 7,000
9163092 #8 x 1-1/2″ A 7.2 5,000
9163094 #8 x 1-3/4″ A 7.8 4,000
9163096 #8 x 2″ A 9.3 4,000
9163098 #8 x 2-1/2″ A 10.7 2,000
9163100 #8 x 3″ A 12.5 2,000
9163102 #10 x 3/8″ AB 4.3 14,000
9163104 #10 x 1/2″ AB 4.7 10,000
9163106 #10 x 5/8″ AB 5.1 10,000
9163108 #10 x 3/4″ AB 60 10,000
9163110 #10 x 1″ A 7.0 8,000
9163112 #10 x 1-1/4″ A 8.4 6,000
9163114 #10 x 1-1/2″ A 9.4 4,000
9163116 #10 x 1-3/4″ A 10.7 4,000
9163118 #10 x 2″ A 12.2 3,000
9163120 #10 x 2-1/2″ A 14.4 2,500
9163122 #10 x 3″ A 17.3 1,500
9163124 #12 x 1/2″ AB 5.8 8,000
9163126 #12 x 5/8″ AB 7.3 7,000
9163128 #12 x 3/4″ AB 7.5 8,000
9163130 #12 x 1″ A 9.4 6,000
9163132 #12 x 1-1/4″ A 10.6 4,000
9163134 #12 x 1-1/2″ A 12.7 3,000
9163136 #12 x 1-3/4″ A 14.4 3,000
9163138 #12 x 2″ A 15.9 2,000
9163140 #12 x 2-1/2″ A 19.2 1,500
9163142 #12 x 3″ A 22.5 1,200
9163144 #14 x 1/2″ AB 10.0 5,000
9163146 #14 x 5/8″ AB 11.1 4,500
9163148 #14 x 3/4″ AB 12.2 5,000
9163150 #14 x 1″ A 14.9 4,000
9163152 #14 x 1-1/4″ A 16.6 3,000
9163154 #14 x 1-1/2″ A 18.5 2,500
9163156 #14 x 1-3/4″ A 21.0 2,000
9163158 #14 x 2″ A 24.0 2,000
9163160 #14 x 2-1/2″ A 27.8 1,500
9163162 #14 x 3″ A 32.1 1,200
9163164 #14 x 3-1/2″ A 36.5 1,000
9163166 #14 x 4″ A 40.1 800
